To better support domestic and international research institutions and enterprises in accessing customized Epitaxial Quenching Resistor (EQR) SiPM, Position Sensitive (PSS) SiPM, APD and PIN prototype, NDL is pleased to announce the launch of a MultiProject Wafer (MPW) service in partnership with Capital Photonics Co., Ltd., starting in Q1 2026.
To secure your participation in an MPW run, please submit your reservation at least five working days prior to the data submission deadline, complete the required checklist, sign the service agreement, and finalize payment. Please note that MPW service adopt a first-come-first-served strategy, if the number of participants for a given run is either insufficient or exceeds capacity, your project may be moved to the next available run.
| Technology | Fab. | Process | Mar | Jul | Oct |
|---|---|---|---|---|---|
| EQR SiPM, PSS SiPM, APD, PIN | 6-inch | Upon Order Quantity | 13 | 3 | 30 |
The active area, microcell pitch, and array size of customized devices are as follows:
| Devices | Microcell Pitch | Active Area of EQR SiPM/PSS SiPM/APD/PIN | ||||||
|---|---|---|---|---|---|---|---|---|
| (0.5-9.5)×9.5 mm² | 6×6 mm² | 3×3 mm² | 1×1 mm² | 0.75×0.5 mm² | 0.5×0.5 mm² | 0.25×0.25 mm² | ||
| EQR/PSS SiPM | 20 μm | 1×1、1×6 | NA* | NA* | 3×3 、1×16 | 1×32 | 4×32 | 8×64 |
| 15 μm | 1×1、1×6 | 1×1 | NA* | 3×3 、1×16 | 1×32 | 4×32 | 8×64 | |
| 10 μm | NA | NA | 1×1 | 3×3 、1×16 | 1×32 | 4×32 | 8×64 | |
| APD/PIN | / | 1×1、1×6 | 1×1 | 1×1 | 1×16 | 1×32 | NA | NA |
